'Alberti' pole top with curved double curl decoration on bracket
Code 501.2
Category: Classical Brackets,
Quantity (pc) :
Description
Specifications
Downloads
Product version
Long UNI EN 1706 aluminum or UNI EN 1561 GJL250 cast iron pole top with mounted curved steel suspension bracket.
The support junctions along the bracket are each made individually in a single casting of nodular cast iron or aluminum; curved bracket tube is prearranged for the passage of cables and threaded 3/4" GAS in the final part for light fixture attachment.
Fit for pole top mounting with poles diam. 60, 70, 89 mm.
Painted black anthracite or any other colore RAL requested.
Surface Protection powder coated 220 micron minim
Total height of pole top is 1200 mm, with a projection of 810 mm.
The support junctions along the bracket are each made individually in a single casting of nodular cast iron or aluminum; curved bracket tube is prearranged for the passage of cables and threaded 3/4" GAS in the final part for light fixture attachment.
Fit for pole top mounting with poles diam. 60, 70, 89 mm.
Painted black anthracite or any other colore RAL requested.
Surface Protection powder coated 220 micron minim
Total height of pole top is 1200 mm, with a projection of 810 mm.
